Product DescriptionCompany Info.<>
- Model:
- QC-8773
- Processing customization:
- Yes
- Overall dimension:
- 600(L)*500(D)*900(H) mm
- Weight:
- 50 ㎏
- Product use:
- The brake power-off switch life tester simulates the performance of the brake power-off switch durin
- Measuring range:
- of No. 5 workstation
Equipment name: Electric vehicle brake power switch life tester
Equipment model: QC-8773
Introduction:
The life tester of brake switch simulates the working state of brake switch during vehicle braking, and continuously operates the switch to evaluate its performance and durability. The equipment is widely used in brake system testing of vehicles such as electric vehicles, and is an important tool to ensure the safety and reliability of brake systems.
How it works:
The life tester simulates the working state of the brake power switch in the process of vehicle braking by controlling the on-off operation of the test fixture. During the test process, the tester will continuously record the on-off times and performance parameters of the brake power-off switch, and automatically stop when the preset test conditions are reached. At the same time, the tester may also be equipped with a specimen damage detection device to monitor the condition of the specimen in real time and automatically stop the test.
Electric vehicle brake switch life tester technical parameters:1. Key load;50g, 100g, 200g, 300g, 500g each 5 g (optional directly into the handle for testing)
2. Test station: 5 groups (independent), optional 8-station synchronous working mode
3. Machine power;500W
4. Number of tests: 0~ 9999999 (settable)
5. Single group count: 999999
6. Test speed;3~60c.p.m adjustable
7. Key stroke;60mm (MAX)
8. Table lift;100mm(MAX)
9. Volume: 600(L)*500(D)*900 (H) mm
10. Weight: 50kg
11. Power supply;220V/50HzElectric vehicle brake power switch life tester operating flow
-
Preparation stage: Check whether the power supply and air supply of the tester are normal, and ensure that the test sample is not damaged and correctly installed on the test fixture.
-
Setting parameters: Set the parameters of the tester according to the test requirements, such as test times, on-off time, etc.
-
Start test: press the start button, the tester starts to run and performs continuous on-off operation.
-
Observation and recording: observe the operation of the brake power switch during the test and record the relevant data.
-
End of test: When the preset number of tests is reached or the test piece is damaged, the tester stops automatically. At this time, the test data can be read and analyzed.
-
Maintenance: Clean up the tester after the test and carry out necessary maintenance work.
